Probe Technical Data
Mechanical
MINIMUM CENTERS: .031 (.79)
FULL TRAVEL: .050 (1.27)
WORKING TRAVEL: .030 (.762)
OPERATING LIFE: 1,000,000 cycles
Electrical
Probe Self Inductance 2.7 nH
Propagation Delay 48 picoseconds
Insertion Loss <0.5 dB to 3.5 GHz
Cross Talk <-10dB up to 3 GHz
Rise Time 87.6 picoseconds
Capacitance 1.04 pF
Material and Finishes
PLUNGER: Heat treated beryllium copper 24 Kt gold
plated over nickel or rhodium plated over nickel *
* For rhodium plating add -R to end of part number;
i.e., 08-1-023-342-R.
BARREL: Preplated gold over nickel silver.
SPRING: 24 Kt gold plated
Spring Force +/- 20% oz. (grams)
| Spring Type |
Preload |
Working Travel |
| -0 |
.54 (15.1) |
1.1 (30.8) |
|
